8-10
8.3.2.2 FPRE217/222 Drain Valve Assembly and Component Parts
ITEM PART # COMPONENT
106-4920 Valve Assembly, Full Vat Drain
1 816-0639 Cap, Red Handle
2 816-0220 Insulation, Drain Safety Switch
3 806-8137 Bracket Assembly, Full-Vat Drain Safety Switch
4 810-2946 Valve, 1.25-inch Full-Vat Drain
5 809-0540 Nut, ½-13 2-Way Hex Lock
6 210-9177 Retainer, Full-Vat Drain Valve Nut
7 824-1602 Handle, Full-Vat Drain Valve
8 210-9178 Cover, Dual Vat Drain Safety Switch
9 826-1366 Nut, 4-40 Keps Hex (Pkg. of 25)
10 807-2103 Microswitch, CE Straight Lever
11 810-1165 Washer, Teflon Drain Valve
12 210-8966 Support, 3” Drain
13 816-0135 O-Ring, Round Drain
* WIR0572 Wire Bundle, Drain Safety Switch
* Not illustrated.
