8-16
8.4.4 Heating Element Assembly and Associated Parts cont.
ITEM PART # COMPONENT
106-5554 Element Assembly FV 440V 17kW w/ Lift Handle Single FPRE117
106-5558 Element Assembly FV 480V 17kW w/ Lift Handle FPRE217
108-1715 Element Assembly FV 230/400V 22 kW w/ Lift Handle FPRE122
106-8547 Element Assembly FV 440V 22 kW w/ Lift Handle FPRE122
106-8546 Element Assembly FV 480V 22 kW w/ Lift Handle FPRE222
1 826-2202 Element, 440V 8.5kW
826-2203 Element, 480V 8.5kW
826-2206 Element, 230/400V 11kW
826-2211 Element, 440V 11kW
826-2209 Element, 480V 11kW
2 826-2212 Probe, Temperature Kit RE (includes tie wraps and grommet)
3 816-0681 Grommet, Probe
4 816-0480 Plug, .375-inch Dome
5 816-0688 Gasket, Element
6 810-1233 Handle, Element Lift SS
7 809-0567 Tie-Wrap, Metal
8 106-5590 Tube Assembly RE Element, Full-Vat
9 106-5588 Bracket Assembly, LH Element Tube Support
10 106-5589 Bracket Assembly, RH Element Tube Support
11 230-0554 Plate, Element Tube Support Inner
12 230-0553 Plate, Element Tube Support Outer
13 106-6569 Bracket Assembly, LH Upper Spring
14 106-6570 Bracket Assembly, RH Upper Spring
15 826-1330 Screw, 10-32 X ⅜-inch Slotted Truss Head SS (Pkg. of 25)
16 809-0766 Nut, 10-32 Hex HD SS
17 809-1000 Screw, 10-32 x 1¼-inch Hex
18 106-6037 Tube, FV Element Mounting
19 810-2993 Bushing, Tube End Teflon
20 230-0850 Bracket, Temperature Probe
21 809-0518 Screw, 8-32 X ⅜-inch Slotted Hex Head SS
22 210-9180 Clamp, Element (Short)
23 230-0781 Clamp, Element (Long)
24 230-0849 Bracket RE, Full-Vat Element Rear
25 823-5657 Bracket RE, Full-Vat Element Front
26 826-1364 Pin, .125 X .5-inch Split (Pkg. of 25)
27 809-1003 Screw, 10-32 X ⅜-inch Hex Head SS (uses 809-0766 Nut 10-32 SS)
28 810-3030 Spring, Element Lift Left
810-3031 Spring, Element Lift Right
810-3339 Spring, Element Lift Left (22 kW)
810-3340 Spring, Element Lift Right (22 kW)
29 220-1190 Bracket, Lower Spring Single Foot Print
220-0464 Bracket, Lower Spring
30 220-0733 Bracket, Lower Spring Mating
* 106-6587 Magnetic Position Sensor
* 810-3007 Magnet
* 230-0794 Bracket, Magnetic Position Sensor Wire
* Not illustrated.
