8.5.1 FPRE117/122 Single Filtration Components cont.
ITEM PART # COMPONENT
106-6519 Assembly, Filter Pan Single FPRE117/122 includes pan and lid
1 106-6516 Lid, Assembly Single FPRE117/122
2 824-1707 Crumb Tray
3 823-5774 Hold Down Ring - Paper
4 220-1316 Sana Grid Filter Screen
5 823-5879 Pan, Filter
6 810-2198 Roller, Filter Pan Rail (used with Item 8 and 9)
* 826-1979 Filter Pan Roller Kit (four each of Items 6 and 826-1372)
* 826-1372 Nut, ¼-20 Hex (Pkg. of 10)
* 810-2012 Rail Set, Filter Pan Roller (includes one left and one right)
7 826-1392 O-Ring (Pkg. of 5; used with Item 5)
8 106-5981 Support, Assy. Left Filter Pan
9 106-5982 Support, Assy. Right Filter Pan
10 823-5862 Fitting, Female Suction Tube
11 826-1270 Motor and Gasket Kit, 220-240V 50/60Hz
826-1712 Motor and Gasket Kit, 110-120V 50/60Hz
12 826-1264 Pump and Gasket Kit
* 807-11973 Viking Pump Seal Kit
13 810-1668 Adapter, ⅝-inch to ½-inch NPT Male
14 810-1680 Flexline, 6.5-inch Oil Return
15 813-0616 Elbow, ST ½-inch x ½-inch NPT 90° SS
16 813-0912 Nipple, ½-inch 2.0-inch SS
17 810-1669 Adapter, ⅝-inch to ½-inch NPT Female
18 810-2343 Tee, ½-inch SS
* 803-0170 Filter Paper
* 106-2852SP Heater Strip Assembly, 208-250V 25W 18”
* 806-5933SP Heater Strip Assembly, 100-120V 25W 18”
* Not illustrated.
