8-22
8.5.2 FPRE217/222 Filtration Components cont.
ITEM PART # COMPONENT
* 826-1979 Filter Pan Roller Kit (four each of Items 7 and 8)
* 826-1980 Service Filter Pan (Item 5 minus Item 2)
* 826-1981 Service Filter Pan Assembly (Service Filter Pan above plus Items 3 and 4)
* 826-1392 O-Ring (Pkg. of 5; used with Item 5)
* 813-0568 Plug, ⅛-inch Socket Head Pipe (component of Item 5; two required)
* 811-1071 Tubing, ¼-inch OD Teflon Vent (sold by the foot)
* 106-2852SP Heater Strip Assembly, 208-250V 25W 18”
* 806-5933SP Heater Strip Assembly, 100-120V 25W 18”
1 823-5130 Lid, Filter Pan
2 810-3161 Crumb Tray (component of Item 5)
3 810-2091 Hold Down Ring
4 200-2124 Sana Grid Filter Screen
5 106-4925 Pan, One-Piece Filter (includes Item 2,)
6 810-2012 Rail Set, Filter Pan Roller (includes one left and one right)
7 810-2198 Roller, Filter Pan and Rail (includes screws)
8 826-1372 Nut, ¼-20 Hex (Pkg. of 10) (use 809-0191 for Washer, Lock ¼-inch)
9 823-4675 Bracket, Lid Support
10 Guide, Filter Pan Lid
210-9000 Left
210-9005 Right
11 809-0503 Screw, 8-32 X ½-inch Slotted Truss Head
12 809-0247 Nut, 8-32 Hex Keps
13 823-5133 Suction Tube
14 210-8979 Rail, Left Filter
15 210-8978 Rail, Right Filter
16 826-1270 Motor and Gasket Kit 220-240V 50/60Hz
826-1712 Motor and Gasket Kit 110-120V 50/60Hz
17 826-3191 Pump and Gasket Kit 4 GPM CCW
816-0093 Gasket, Pump/Motor
18 807-2484 Valve, ¼-inch Solenoid
19 810-2493 Fitting, ¼ -inch x 90° Quick Connect
20 813-0342 Elbow, ½-inch 45° Street
21 813-0530 Tee, ½-inch X ¼-inch X ½-inch Reducing
22 813-0087 Nipple, ½-inch Close
23 813-0838 Nipple, ¼-inch Close
24 813-0304 Bushing, ½-inch to ¼-inch Flush
25 810-1668 Adapter, ⅝-inch to ½-inch NPT Male
26 810-1669 Adapter, ⅝-inch to ½-inch NPT Female
27 810-1680 Flexline, 6.5-inch Oil Return
28 810-1057 Flexline, 13.0-inch Oil Return
29 810-1043 Flexline, 11.5-inch Oil Return
30 807-3828 Cable, FootPrint Pro Pump Motor
31 826-1375 Screw, 10-32 X ¾-inch Hex Trim Head (Pkg. of 5)
32 210-9016 Bridge, Filter Motor
33 813-0003 Tee, ½-Inch
34 813-0298 Nipple, ½-inch 2.0-inch
35 813-0537 Nipple, ¼-inch 2.0-inch
* 810-1043 Flexline, 9.5-inch Oil Return
* 803-0170 Filter Paper
* Not illustrated
