8-24
8.7 Oil Return System Components cont.
ITEM PART # COMPONENT
1 106-5848 Handle Assembly, Rear Flush
2 813-0907 Cap, 15/16-inch Valve Safety
3 807-2103 Microswitch, Straight Lever
4 106-5847 Bracket Assembly
5 210-8998 Bracket, Handle Retainer
6 816-0220 Insulation, Oil Return Microswitch
7 826-1366 Nut, 4-40 Keps Hex (Pkg. of 25)
8 810-3105 Rod, Handle
9 816-0643 Grip, Oil Return Valve Handle
10 809-0601 Clip, Clevis
11 810-2532 Flexline, 7.0-inch
* 810-1057 Flexline, 13.0-inch
12 810-1668 Adapter, ⅝-inch to ½-inch NPT Male
13a 813-0616 Elbow, ½-inch X 90° SS
* 813-0899 Elbow, ½-inch X 90° SS (used with 813-0905)
* 813-0905 Nipple, ½-inch x 1.50 SS NPT
13b 813-0908
Adapter, ½-inch NPT M/T 90º (used only on side next to cabinet)
14 810-2944 Valve, ½-inch Ball
15 210-8999 Handle, Rear Flush Valve
16 210-9203 Retainer, Oil Return Valve Nut
17 813-0913 Nipple, ½-inch x 3.0-inch SS
18 810-3015 Manifold, Rear Oil Return Two-Station Fryer
To Next Page
