8.9 Wiring Connectors, Pin Terminals, Seals, and Power Cords cont.
ITEM PART # COMPONENT
Power Cords
* 807-3834 Cable, 3-Phase 4-Wire (Fryer Power Cable)
* 106-6530 Cord, Filter System Power 220V 15A
Connectors
1 807-1068 2-Pin Female
2 807-3232 4-Pin Female
3 807-0158 6-Pin Female
4 807-0156 9-Pin Female
5 807-0159 12-Pin Female
6 807-0875 15-Pin Female
7 807-1067 2-Pin Male
8 807-2078 4-Pin Male
9 807-0157 6-Pin Male
10 807-0155 9-Pin Male
11 807-0160 12-Pin Male
12 807-0804 15-Pin Male
Universal Mate-N-Lock Seals
13 816-0675 4-Pin Wire Seal
14 816-0676 4-Pin Interface Connector Seal
15 816-0667 6-Pin Wire Seal
16 816-0668 6-Pin Interface Connector Seal
17 816-0669 9-Pin Wire Seal
18 816-0670 9-Pin Interface Connector Seal
19 816-0671 12-Pin Wire Seal
20 816-0672 12-Pin Interface Connector Seal
21 816-0673 15-Pin Wire Seal
22 816-0674 15-Pin Wire Seal
23 826-1341 Terminal, Female Split Pin (Pkg of 25)
24 826-1342 Terminal, Male Split Pin (Pkg of 25)
25 807-2518 Plug, Mate-N-Lock (Dummy Pin)
* Not illustrated.
To Next Page
