- 7 -
Display in every mode:
Safety one process
Selection mode 1 2 3 4 5 6 7 8
※1
9
Peak / instantaneous LED
※2
○ ○ ○ ○ ○ ○ ○ ○
Return/setting LED
Return ─ ─ ─ ─ △ △ △ ─
Setting ○ ─ ○ ─ ─ ─ □ ○
Mode display (digital)
※3
1 2 3 4 5 6 7 9
Timer display (digital)
※4
─ ○ ○ ○ ○ ○ ─ ─
○: Display or lighting up
─: Non-display
△: After starting, lamp lights up and digital display is carried out just after zero point returning to next starting.
□: Lamp lights up and digital display is carried out until reset is operated or press hold signal is input after starting.
※1: Mode 8 is specific specifications. (Refer to us for specifications etc.)
※2: After starting, either lamp for peak or instantaneous lamp flashes (lights up).
※3: Digital number (modes 1 to 9) is displayed.
※4: Digital number (0.0 sec. to 9.9 seconds.) is displayed.
Die matching
Each LED for peak, instantaneous, return and setting and each digital display for return / setting, mode, alarm and timer turn
off light.
Necessary wiring (input) and alarm display in every mode
●: Necessary; ▲: Wiring is possible; ×: Not necessary
Input signal A B 1 2 3 4 5 6 7 8 9
Press start 10-12 ● ● ● ● ● ● ● ●
Press upper limit 7-8 ● ● ● ● ● ● ● ×
Press hold limit 6-8 ● ● ● ● ● ● ● ×
Measurement start 3-4 × × × × ▲ ▲ ▲ ▲
Measurement end 2-4 × × × × ● ● ● ●
External 1-4 × × × ● × ● × ×
Emergency stop 11-12 ▲ ▲ ▲ ▲ ▲ ▲ ▲ ×
Press start: This is a start order. A: Terminal base; B: Mode
Press upper limit: Input is carried out when press ram is upper limit (zero point). (Contact point a)
Start lamp lights up simultaneously when input is carried out.
Press hold: After press start signal is input and press ram moves upper limit, the input is carried out on the way of descending
(moving). (Contact point a) Hold lamp lights up simultaneously when input is carried out.
Measurement start: Input is carried out after press start signal is input. (Contact point a)
Sensor CUT lamp lights up simultaneously when input is carried out. If wiring is not carried out, measurement
starts simultaneously when start is applied.
Measurement end: Input is carried out after press hold limit signal and load measurement start signal are input.
(Contact point b) Sensor END lamp lights up simultaneously when input is carried out.
External: Input is carried out after press hold signal is input. (Contact point a)
Emergency stop: This is effective only when operation function switching switch is in “Safety one process” and
electromagnetic valve is operating. This is not operated when press ram is returning to zero point.
