Specifications (Measuring instruments/Load-cell)
Measuring instrument specifications
Type CP-2
Display Four-figure display
Decimal point Possible to set to the optional position
Zero point correction Automatic correction in every start signal input
Span Internal computation processing by the ten-key input
Load calibration Calibrated using actual loads at the time of shipment
Set value for comparison Ten patterns of upper/lower limit value are memorized
Set value of the load Ten patterns are memorized
Timer control
0 to 9.9 seconds (Possible to change between 0 to 99 seconds)
* For change method, please contact us separately)
Output signal
Press cylinder upper/lower limit position signal relay contact point output
Comparison signal relay output (LO, GO, HI)
Set load attainment signal photo coupler open collector output
Electromagnetic valve driving
output
AC100V; Standard: Two circuits; (Three circuits are provided only for the specific
mode)
Speed of internal system Approximately 4000 times/second
Load measuring range Refer to the following “Load digital display portion” item
Accuracy of load display 0.5% (FS) +/- 1 digit (23.0 +/- 3℃) in whole range of load-cell
Motion mode Nine types
Dimensions (mm)
W: 96 × D: 175 × H: 206 (excluding protruding portions)
Refer to the drawing in Page 25
Weight 2,400gr (excluding load-cell)
Power source AC100V +/- 10%, 50/60Hz
Combination load-cell specifications:
Configuration Ram shank installed type Ultra thin type Ultra compact type Lower mount type
Model 003 03 10(U) 20(U) 003F1 03F1 003L 01L 10(L)
Rated capacity 3kN 30kN 100kN 200kN 3kN 30kN 3kN 10kN 100kN
Allowable ext
ra load
150%
150%
120%
120%
120%
120%
120%
120%
120%
Input/output r
esistance
Approx.
350Ω
Approx.
350Ω
Approx.
700Ω
Approx.
700Ω
Approx.
350Ω
Approx.
350Ω
Approx.
350Ω
Approx.
350Ω
Approx.
350Ω
Cable length 2m 2m 2m 2m 2m 2m 1.5m 1.5m 3m
Accuracy 0.5% F.S. +/- 1 digit (23.0℃+/- 3℃): (OP 1 and overall) ※However, regarding 003L and 01L, 1.0% F.S. +/- 1 digit
Unit in display* 0.001kN 0.01kN 0.1kN 0.1kN 0.001kN 0.01kN 0.001kN 0.01kN 0.1kN
* Unit in display is the indication when connected to the controller.
Digital load display portion: Upper limit comparison value. Lower limit comparison value is also the same display.
Model Value shown in the display
CP-2-03 (For F1, L1 is also the same) 0.00kN to 30.00kN
CP-2-003 (For F1, L1 is also the same) 0.000kN to 3.000kN
CP-2-10U or 10L 0.0kN to 100.0kN
CP-2-20U 0.0kN to 200.0kN
Method of determining model:
Model of press controller for the load control device is determined by the combination of measuring instrument and load-cell.
For example, in the case that load-cell with the rated load of 3kN, and ram shank installed type are combined with the CP-2
measuring instrument, the combination becomes [CP-2] + [003]. And, the model of press controller is “CP-2-003.”
If ultra thin type load-cell with 3kN rated load is combined, the combination becomes [CP-2] + [003F1]. And, the model is
“CP-2-003F1.”
