7.4 I/O Assembly Instances Assigned to Word Variables (For reference)
Some masters assign an I/O assembly instance area to a word variable. Shown below are the formats for each
I/O assembly instance assigned to a word variable. For details about the definition of bits in the formats, refer to
Section 7.2, "I/O ASSEMBLY INSTANCES: SELECTION AND SETUP."
(1) Basic Speed Control Instance
Output (from master to this option): o31=20
word bit15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bit0
0 - - - - - - - - - - - - - Fault
Reset
- Run
Forward
1 Speed Reference (r/min)
Input (from this option to master): o32=70
word bit15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bit0
0 - - - - - - - - - - - - - Running
Forward
- Faulted
1 Speed Actual (r/min)
(2) Extended Speed Control Instance
Output (from master to this option): o31=21
word bit15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bit0
0 - - - - - - - - - Net
Ref
Net
Ctrl
- - Fault
Reset
Run
Reverse
Run
Forward
1 Speed Reference (r/min)
Input (from this option to master): o32=71
word bit15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bit0
0 - - - - - - - - At
Reference
*2 *1 Ready Running
Reverse
Running
Forward
- Faulted
1 Speed Actual (r/min)
*1 CtrlFromNet
*2 RefFromNet
(3) Fuji Drive Assembly Instance
Output (from master to this option): o31=100
word bit15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bit0
0 RST XR XF - - - - - - X5 X4 X3 X2 X1 REV FWD
1 Frequency command p.u.
Input (from this option to master): o32=101
word bit15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 bit0
0 BUSY ERR - RL ALM DEC ACC IL VL TL NUV BRK INT EXT REV FWD
1 Frequency command p.u.
