Chapter 12 SPECIFICATIONS
12.1 General Specifications
For the items not covered in this section, the specifications of the inverter apply.
Item Specifications
Power input voltage 21.6 to 27.0 V
Input power 35 mA at maximum (24 VDC) (not included network input power)
Operating ambient temperature range -10 to +50°C
Operating ambient humidity range 5 to 95% RH (There shall be no condensation.)
External dimensions 79.6 x 127 x 47.5 mm
Applicable inverter FRENIC-Multi, ROM version: 0700 or later
12.2 DeviceNet Specifications
For the items not covered in this section, the DeviceNet Specifications Release 2.0 apply.
Item Specifications
Network input voltage 11 to 28 V
Network power consumption 75 mA at maximum (24 VDC)
No. of nodes connected 64 at maximum (including the master)
MAC ID 0 to 63
Insulation 500 VDC (photocoupler insulation)
Transmission rate 500 kbps/250 kbps/125 kbps
Transmission rate 500 kbps 250 kbps 125 kbps
Trunk line length 100 m 250 m 500 m
Drop line length 6 m 6 m 6 m
Maximum cable length
(Trunk line: thick cable
Drop line: thin cable)
Total length of drop lines 39 m 78 m 156 m
Messages supported 1. I/O Message (Poll, Change of State)
2. Explicit Message
Vendor ID 319 (Fuji Electric Co., Ltd.)
Device type AC drive (code: 2)
Product code 9218
Model name OPC-E1-DEV
Applicable device profile AC Drive
No. of input/output bytes Selectable between 4 and 8 bytes for input and output (independently)
Applicable DeviceNet
Specifications
DeviceNet Specifications Release 2.0 Errata 5
(Certified by ODVA Japan for Conformance Test Version A-18)
Node type Group 2 only server
