7.2 I/O Assembly Instances: Selection and Setup
(1) Basic speed control instance
Output (from master to this option): o31=20
Instance byte bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
0 - - - - - Fault
Reset
- Run
Forward
1 (Fixed at 00)
2 Speed Reference (lower byte) (r/min)
20
3 Speed Reference (upper byte) (r/min)
Run Forward: 1 = Run forward command
Fault Reset: 1 = Reset the alarm condition
Speed Reference: Speed command (in r/min)
Input (from this option to master): o32=70
Instance byte bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
0 - - - - - Running
Forward
- Faulted
1 (Fixed at 00)
2 Speed Actual (lower byte) (r/min)
70
3 Speed Actual (upper byte) (r/min)
Faulted: 1 = The inverter has (and remains) tripped
Running Forward: 1 = The motor is running forward.
Speed Actual: Actual rotation speed (in r/min)
