5-58
For P99, enter the following data according to the motor type.
• P99 = 0 (Motor characteristics 0): Fuji standard 8-series motors (Current standard)
• P99 = 3 (Motor characteristics 3): Fuji standard 6-series motors (Conventional standard)
• P99 = 4 (Other motors): Other manufacturer’s or unknown motors
• If P99 = 4 (Other motors), the inverter runs following the motor characteristics o
Fuji standard 8-series.
• The inverter also supports motors rated by HP (horse power: typical in North
America, P99 = 1).
H03 Data Initialization
H03 initializes the current function code data to the factory defaults or initializes the motor
parameters.
To change the H03 data, it is necessary to press the
+ keys or + keys
(simultaneous keying).
Data for H03 Function
0
Disable initialization
(Settings manually made by the user will be retained.)
1 Initialize all function code data to the factory defaults
2
Initialize motor 1 parameters in accordance with P02 (Rated capacity) and
P99 (Motor 1 selection)
Function codes subject to initialization: P01, P03, P06 to P12 and constants
for internal control
(These function codes will be initialized to the values listed in tables on the
following pages.)
3
Initialize motor 2 parameters in accordance with A16 (Rated capacity) and
A39 (Motor 2 selection)
Function codes subject to initialization: A15, A17, A20 to A26 and constants
for internal control
(These function codes will be initialized to the values listed in tables on the
following pages.)
• To initialize the motor parameters, set the related function codes as follows.
1) P02/A16
Motor (Rated
capacity)
Set the rated capacity of the motor to be used in HP or kW.
2) P99/A39
Motor Selection
Select the characteristics of the motor.
3) H03 Data Initialization Initialize the motor parameters. (H03 = 2 or 3)
4) P03/A17
Motor (Rated current)
Set the rated current on the nameplate if the already set data
differs from the rated current printed on the nameplate of the
motor.
• Upon completion of the initialization, the H03 data reverts to "0" (factory default).
• If the P02 or A16 data is set to a value other than the nominal applied motor rating, data
initialization with H03 internally converts the specified value forcedly to the equivalent
nominal applied motor rating (see the tables on the next page).
