Fuji Electric FRENIC-Multi - Page 142

5-59
 When Fuji standard 8-series motors (P99 = 0) or other motors (P99 = 4 or A39
= 4) are selected, the motor parameters are as listed in the following tables.
230 V class series
Motor
capacity
(HP)
Rated
current
(A)
No-load
current
(A)
%R
(%)
%X
(%)
Rated slip
frequency
(Hz)
P02/A16
Norminal
applied
motor
(HP)
P03/A17 P06/A20 P07/A21 P08/A22 P12/A26
0.01 to 0.11 0.10 0.44 0.40 13.79 11.75 2.50
0.12 to 0.24 0.12 0.68 0.55 12.96 12.67 2.50
0.25 to 0.49 0.25 1.40 1.12 11.02 13.84 2.50
0.50 to 0.99 0.50 2.00 1.22 6.15 8.80 2.50
1.00 to 1.99 1.00 3.00 1.54 3.96 8.86 2.50
2.00 to 2.99 2.00 5.80 2.80 4.29 7.74 2.50
3.00 to 4.99 3.00 7.90 3.57 3.15 20.81 1.17
5.00 to 7.49 5.00 12.60 4.78 3.34 23.57 1.50
7.50 to 9.99 7.50 18.60 6.23 2.65 28.91 1.17
10.00 to 14.99 10.00 25.30 8.75 2.43 30.78 1.17
15.00 to 19.99 15.00 37.30 12.70 2.07 29.13 1.00
20.00 to 24.99 20.00 49.10 9.20 2.09 29.53 1.00
25.00 to 29.99 25.00 60.00 16.70 1.75 31.49 1.00
30.00 30.00 72.40 19.80 1.90 32.55 1.00
460 V class series
Motor
capacity
(HP)
Rated
current
(A)
No-load
current
(A)
%R
(%)
%X
(%)
Rated slip
frequency
(Hz)
P02/A16
Norminal
applied
motor
(HP)
P03/A17 P06/A20 P07/A21 P08/A22 P12/A26
0.01 to 0.11 0.10 0.22 0.20 13.79 11.75 2.50
0.12 to 0.24 0.12 0.34 0.27 12.96 12.67 2.50
0.25 to 0.49 0.25 0.70 0.56 11.02 13.84 2.50
0.50 to 0.99 0.50 1.00 0.61 6.15 8.80 2.50
1.00 to 1.99 1.00 1.50 0.77 3.96 8.86 2.50
2.00 to 2.99 2.00 2.90 1.40 4.29 7.74 2.50
3.00 to 4.99 3.00 4.00 1.79 3.15 20.81 1.17
5.00 to 7.49 5.00 6.30 2.39 3.34 23.57 1.50
7.50 to 9.99 7.50 9.30 3.12 2.65 28.91 1.17
10.00 to 14.99 10.00 12.70 4.37 2.43 30.78 1.17
15.00 to 19.99 15.00 18.70 6.36 2.07 29.13 1.00
20.00 to 24.99 20.00 24.60 4.60 2.09 29.53 1.00
25.00 to 29.99 25.00 30.00 8.33 1.75 31.49 1.00
30.00 30.00 36.20 9.88 1.90 32.55 1.00
