Stapler Faults
507
Problem Solving
15
2 Grasp the handle as shown in the illustration
to pull out the staple cartridge to the right,
towards you.
3 Move up the staple cartridge, and then take
it out of the machine.
Note • The staple cartridge is firmly inserted. A
slight force is required to pull the cartridge
out of the finisher.
4 After you take out the staple cartridge, check
inside of the finisher for any remaining
staples.
5 Pull up the metal part of the staple cartridge
as shown in the illustration.
6 Remove the jammed staples (c), and then
return the metal part pulled up in step 5 to
the original position (
d).
