Installing the Extension System Memory (2 GB) (Optional)
611
Appendix
16
5 Remove the rear left cover.
6 Remove the memory card already inserted.
Push the retaining clips on both ends in the
outward direction and pull the memory card
straight out.
Important • When removing the memory card, be
careful not to drop the card.
7 Insert a memory card straight into the slot.
Note • Push the memory card as far as it can go
to secure it.
• When the memory card is installed
correctly, the retaining clips on both ends
will snap into the locked position.
8 Re-attach the rear left cover.
9 Tighten the two screws by turning them
clockwise.
