Paper Jams
599
Problem Solving
15
4 Move the handle [2a] to the right, and remove
the jammed paper.
5 Pull down the handle [2b] (1), and remove the
jammed paper (2).
6 Return the handle [2a] and [2b] to the original position.
7 Insert the transfer module completely (1), and
turn the green handle [2] to the left (2).
Note • If you cannot turn the handle, pull the
transfer module out to the middle and insert
it again.
8 Close the machine front door.
Note • A message will be displayed and the machine will not operate if the machine front door is even
slightly open.
Paper Jams in the Bottom Left Door
1
If Tray 6 (HCF2 (2000 sheets)) is installed,
gently move Tray 6 to the left until it stops by
gripping the handle on the top left side of Tray
6.
To Next Page
