3 Maintenance
86
Maintenance
3
9 Slightly push the booklet staple cartridge
upward, and make sure that it clicks into place.
Note • Return the booklet staple cartridge until ( )
of the booklet staple cartridge is fitted in ( )
of the booklet unit.
10 Return the booklet unit to its original position.
11 Close the finisher front door.
Note • If the front door is not closed completely, a message appears and the machine will remain paused.
Replacing the Booklet Staple Cartridge (Finisher D2-P with Booklet Maker)
When the Finisher D2-P with Booklet Maker (optional) is installed and it is time to replace
the booklet staple cartridge, a message appears on the touch screen. When this message
appears, replace the staple cartridge with a new one.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and performance.
Use only staple cartridges recommended by Fuji Xerox for the machine.
Note • If the staple cartridge was not replaced properly, the message remains on the touch screen. Follow
the procedure and replace the staple cartridge again.
• To order a staple cartridge, contact our Customer Support Center.
1 Make sure that the machine has stopped, and
open the front cover of the finisher.
2 While pressing the levers R2 and R3 to the right
(1), pull out the unit (2).
To Next Page
