202 7 Maintenance
5. Gently wipe the glass window at the back of
the cartridge slot with a soft dry cloth.
6. Hold the drum cartridge by the handles with
both hands. Gently insert the drum
cartridge in the printer, aligning the
projections marked with arrows on both
sides with the arrow labels on the printer.
7. Close the output tray cover.
Important
• When closing the output tray cover, be careful not to
get your fingers caught between (the left or right edge
of) the cover and the printer.
8. Close the front cover.
Important
• When closing the front cover, be careful not to get your
fingers caught between (the left, right, top, or bottom
edge of) the cover and the printer.
To Next Page
