Specifications
267
Appendix
13
Note • Even if the power of this machine is switched off, it will use up power of 12 W or less. To
avoid the consumption of this power, you have to turn the power breaker of the printer (main
power switch) off and unplug from the power outlet of the scanner.
Copy Media
Plain 64 to 81.4 g/m
2
Vellum 55 to 112 g/m
2
Film 75 to 100 um
Important • It is recommended to use Fuji Xerox recommended paper.
Copying may not be performed correctly depending on the
use conditions.
Image size Width :210 to 914mm
Length:210 to 15,000mm
Image Loss Roll paper top: 5 mm, bottom: 5 mm, right&left: 5 mm
(When outside diameter of the roll is 100 mm or less: Top 8 mm,
Bottom 8 mm)
Power Supply Printer area: AC208-240V +/- 10%, 13A, 50/60 Hz common use
Scanner area: AC208-240V +/- 10%, 13A, 50/60 Hz common
use
Maximum Power Con-
sumption
Max: Scanner area: 480W, Printer area: 3.2kW
Low power mode: 16.5W or less (MF)/13.0W or less (EP)
Warm-up Time 240 seconds or less (when the room temperature is 22°C,
humidity 55 %)
Dimensions [DocuWide 6035/6055 MF]
Width: 1,305 x depth: 707 x height: 1,108 mm
[DocuWide 6035/6055]
Width: 1,305 x depth: 707 x height: 947 mm
Space Requirement Width: 1,305 x depth: 707mm
Weight
*3
(Excluding Paper and
Options)
[DocuWide 6035/6055 MF] [DocuWide 6035/6055]
2-roll model:
4-roll model:
285 kg
326 kg
244 kg
285 kg
Important • The weight is without any toner and paper.
*1 : The scanner and the printer are integrated in one unit.
*2 : This is the speed when feeding from the upper-level Roll Tray.
However, the speed may decrease due to image adjustment. Also, productivity may decrease depending on the media type.
*3 : This weight excludes toner and media.
Item Description
To Next Page
