Printer Settings
247
System Settings
11
[System Settings]>[System Settings]>[Printer Settings]
Other Settings
This screen allows you to set the drawing options
for each data format.
The factory default values do not need to be
changed under normal conditions.
The following items can be set:
Items Notes Factory
Default
VPI-DottedLineAlloc Set the processing method for dotted line alloca-
tion.
Select [RASTERIZER] or [PARSER].
RASTERIZER
VPI-Symbol Select [Mode 1] or [Mode 2]. Mode 1
VPI-Font Number Set whether to use the fonts specified in the data
or to forcibly use the fonts you specify. Select from
[0] to [41].
0
VPI-Font Priority Set whether or not use the font number specified
in the data. Select [Job] or [Controller].
Job
TIFF-Decomp/Comp Set the mode of compression and decompression
for uncompressed TIFF data.
Select [PHOTO] or [LINE].
HPGL-Draw Arc Set the drawing method for arcs.
Select [Follow Allocation Command] or [Ignore
Allocation Command].
Ignore Allocation
Command
HPGL-Draw Dotted
Line
Set the drawing method for dotted lines.
Select [NORMAL] or [EXTEND].
NORMAL
Label Offset X Set the drawing position of the label in X-direction
relative to the corner of the media. Select from [0]
to [100](mm).
5
Label Offset Y Set the drawing position of the label in Y-direction
relative to the corner of the media. Select from [0]
to [100](mm).
3
Allocation Mark Off-
set
Specify the allocation mark drawing position in the
width direction relative to the corner of the media.
Specify in the range of [0] to [100](mm).
3
Allocation Mark
Overlap
Specify the allocation mark drawing position in the
length direction relative to the corner of the media.
Specify in the range [0] to [400](mm).
0
Long Edge Det. Set whether or not to determine the long edge. Off
Other Settings
Page
1 of 4
RASTERIZER
Mode 1
0
Job
1.VPI-DottedLineAlloc
2.VPI-Symbol
3.VPI-Font Number
4.VPI-Font Priority
5.TIFF-Decomp/Comp
Close
Items Current Settings
To Next Page
