Using your notebook
10600690747, edition 1 39
Microphone and loudspeakers
1
2
4
3
1 = Built-in loudspeakers
2 = Bass loudspeaker (subwoofer)
3 = Built-in microphone
4 = Volume control
Two loudspeakers (1), a bass loudspeaker (2), and a microphone (3) are installed in your notebook.
The bass loudspeaker and the two loudspeakers form a so-called subwoofer system for true listening
pleasure. Internal loudspeakers are used to produce the treble and mid-range tones. The bass
loudspeaker is used to produce the bass tones. As these bass tones are not perceived directionally,
only one bass loudspeaker is necessary and the installation location is not important (underside of
the notebook).
i
If you attach an external microphone, the built-in microphone is disabled.
If you attach headphones or external loudspeakers, the built-in loudspeakers are disabled.
Adjusting the volume
► Set the desired volume with the key combination Fn + F5 or Fn + F6 .
or
► To adjust the volume use the Windows volume control from the Start menu - Programs -
Accessories - Multimedia - Volume Control.
or
► Set the desired volume with the volume control.
