Removing and installing components during servicing
60 10600690747, edition 1
Removing and installing the battery
i
How to remove and reinstall a battery is described in chapter "Using your notebook", in the
section "Removing and installing the battery".
Installing and removing the hard disk
Removing the hard disk
► Switch the notebook off and pull the power plug out of the mains socket.
► Close the LCD screen so that it locks into place.
► Disconnect all cables connected to the notebook.
► Turn your notebook over and place it on a sturdy, flat surface.
► Remove the battery (see "Removing battery").
1
1
2
► Remove the screws (1).
► Pull off the cover from the notebook in the direction of the arrow (2).
