Removing and installing components during servicing
10600690747, edition 1 67
Removing a memory module
3
2
1
1
► Carefully push the two mounting clips outwards (1).
The memory module will flap upward (2).
► Pull the memory module out of its slot in the direction of the arrow (3).
Installing a memory module
a
1
2
► Insert the memory module with the contacts and the recess (a) facing the slot (1).
► Carefully push the memory module downwards until it engages noticeably (2).
