3. OUTDOOR UNIT & BRANCH BOX
SPECIFICATIONS1.
OUTDOOR UNIT1-1.
Model name AO

G45LBT8
Power source 1ø 230V ~ 50Hz
Available Voltage Range 198-264V
Connectable indoor unit
Number 2 to 8
Capacity 80 to 130%
Capacity
Cooling
Rated
kW 14.0
Btu/h 48,000
Heating
kW 16.0
Btu/h 54,000
Input power *1
Cooling
Rated kW
5.20
Heating 5.07
Current *1
Cooling
Rated A
23.1
Heating 22.5
EER Cooling
Rated kW / kW
2.69
COP Heating 3.16
Fan
Type × Q'ty Propeller ×1
irow
rate
Cooling
m
3
/h
4,650
Heating 4,800
Motor
Type × Q'ty DC motor ×1
Output W 111
Sound power level Cooling
dB(A)
71
Sound pressure level *2
Cooling
Rated
56
Heating 58
Heat exchanger
Dimension mm 864×955×57.2
Fin pitch mm 1.8
Rows × Stages 3 × 34
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Corrugate (Aluminium)
Surface treatment Corrosion resistance (Blue Fin)
Compressor
Type × Q'ty DC TWIN ROTARY ×1
Motor output W 2700
Crankcase heater W 25
Refrigerant
Type R410A
Charge g 3450
Refrigerant oil Type PVE
Enclosure
Material Painted galvanized steel
Colour
Beige
(Approximate colour of MUNSELL 10YR 7.5/1.0NN)
Dimensions
Net
(H x W x D) mm
914 x 970 x 370
Gross 1048 x 1064 x 479
Weight
Net
kg
98
Gross 106
Connection pipe
Size
Liquid
mm
9.52
Gas
15.88
Method Flare
Max. length (Total)
m
115
Max.length (BP-IN) 15
Max. height difference between
Outdoor Unit and each Indoor Units.
30
Max. height difference between
Indoor Units.
30
Operation range
Cooling
°C
-5 to 46
Heating -15 to 24
NOTE:
pecications are based on the oowing conditions.
*1: In case of connecting two indoor units (7 kW class).
*2: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the
specied aues here.
Power source o specications   
Cooling:Indoor temperature of 27 °CDB /19 °CWB,and outdoor temperature of 35 °CDB/24 °CWB.
Heating:Indoor temperature of 20 °CDB / 15 °CWB,and outdoor temperature of 7 °CDB/6 °CWB.
Pipe length : 5 m [Outdoor unit - Branch box], 3 m [Branch box - Indoor unit]
Height difference : 0 m [Outdoor unit - Indoor unit].
The protective function may work when using it outside the operation range.
- (03 - 01) -
OUTDOOR UNITS OUTDOOR UNITS

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
