3. OUTDOOR UNIT & BRANCH BOX
BRANCH BOX1-2.
Model name UTP-PY03A UTP-PY02A
Casing color Paintingless Paintingless
Connectable indoor unit 1 to 3 Units 1 to 2 Units
Power source 1ø 230V ~ 50Hz 1ø 230V ~ 50Hz
Available voltage range 198-264V 198-264V
Input Power W 10 10
Running current A 0.05 0.05
Refrigerant type R410A R410A
Dimensions
(H × W × D)
Net
mm
195×433×370 195×433×370
Gross 271×931×436 271×931×436
Weight
Net
kg
9 9
Gross 13 13
Connection
pipe
Size
Liquid
mm
Main : 9.52 ×1, Branch : 6.35 ×3 Main : 9.52 ×1, Branch : 6.35 ×2
Gas Main : 15.88 ×1, Branch : 12.7 ×3 Main : 15.88 ×1, Branch : 12.7 ×2
Method Flare Flare
Operation range
°C -15 to 46 -15 to 46
%RH 80 or less 80 or less
Note :
pecications are based on the oowing conditions.
Power source o specications  .
- (03 - 02) -
OUTDOOR UNITS OUTDOOR UNITS

Fujitsu ABHG18LVTB Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Drain hose diameter	25 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	5900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	7500 W
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-15 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	9 A
Current (heating)	12.5 A
AC input frequency	50 Hz
Design load (cooling)	5.2 kW
Energy efficiency class (cooling)	A++
Annual energy consumption (cooling)	298 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1819 kWh
Indoor unit depth	655 mm
Indoor unit width	990 mm
Indoor unit height	199 mm
Indoor unit weight	27000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	- dB
