Removing and installing components
during servicing
Devices with separate compartments for memory and hard disk
1
2
► Attach the cover in the direc tion
of the arrow (1).
► Secure the cover with the screw s (2).
► Reinstall the battery (see "
Removing and installing the battery" , Page 30).
► Turn the notebook the right way up and place it on a flat surface.
► Reconnect the cab les that you disconnected previously.
A26391-K90-Z200-1-7619, edition 1 67
