Fujitsu ASUH12LMAS Design & Technical Manual

¢
Model: ASUH12LMAS
AFR CFM 453
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
14 13.03 8.87 0.84 14.50 9.21 0.86 15.59 9.59 0.88 16.28 10.58 0.89 16.86 10.85 0.99 17.03 11.33 1.02
23 12.80 8.63 0.86 14.26 8.97 0.88 15.32 9.25 0.90 16.00 10.13 0.91 16.58 10.41 1.01 16.75 10.88 1.04
32 12.59 8.39 0.88 14.02 8.70 0.90 15.08 9.04 0.92 15.73 9.72 0.93 16.28 10.00 1.03 16.45 10.44 1.07
41 12.35 8.19 0.91 13.78 8.53 0.93 14.81 8.80 0.95 15.46 9.35 0.96 16.00 9.62 1.06 16.17 10.03 1.10
50 12.11 8.02 0.93 13.51 8.29 0.96 14.50 8.60 0.98 15.15 9.01 0.99 15.70 9.25 1.10 15.83 9.66 1.13
59 11.91 7.85 0.97 13.24 8.12 1.00 14.26 8.36 1.02 14.88 8.70 1.03 15.39 8.91 1.14 15.56 9.31 1.18
67 11.43 7.71 1.03 12.69 7.95 1.05 13.65 8.22 1.08 14.26 8.53 1.09 14.77 8.73 1.21 14.91 9.14 1.25
77 11.16 7.51 1.20 12.42 7.75 1.22 13.34 7.98 1.25 13.92 8.29 1.27 14.43 8.53 1.40 14.57 8.91 1.45
87 10.48 7.23 1.29 11.64 7.47 1.32 12.52 7.71 1.35 13.07 8.02 1.37 13.55 8.22 1.51 13.68 8.56 1.57
95 9.62 7.06 1.33 10.71 7.30 1.36 11.50 7.54 1.39 12.00 7.92 1.41 12.45 8.02 1.56 12.56 8.39 1.62
104 7.78 5.80 0.94 8.36 6.24 0.95 8.84 6.59 0.97 9.31 6.89 0.98 9.72 7.10 0.99 10.20 7.37 0.99
115 6.65 4.88 1.01 7.13 5.25 1.03 7.54 5.56 1.05 7.95 5.83 1.06 8.29 6.01 1.07 8.70 6.21 1.07
AFR
m
3
/h
770
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 3.82 2.60 0.84 4.25 2.70 0.86 4.57 2.81 0.88 4.77 3.10 0.89 4.94 3.18 0.99 4.99 3.32 1.02
-5.0 3.75 2.53 0.86 4.18 2.63 0.88 4.49 2.71 0.90 4.69 2.97 0.91 4.86 3.05 1.01 4.91 3.19 1.04
0.0 3.69 2.46 0.88 4.11 2.55 0.90 4.42 2.65 0.92 4.61 2.85 0.93 4.77 2.93 1.03 4.82 3.06 1.07
5.0 3.62 2.40 0.91 4.04 2.50 0.93 4.34 2.58 0.95 4.53 2.74 0.96 4.69 2.82 1.06 4.74 2.94 1.10
10.0 3.55 2.35 0.93 3.96 2.43 0.96 4.25 2.52 0.98 4.44 2.64 0.99 4.60 2.71 1.10 4.64 2.83 1.13
15.0 3.49 2.30 0.97 3.88 2.38 1.00 4.18 2.45 1.02 4.36 2.55 1.03 4.51 2.61 1.14 4.56 2.73 1.18
19.4 3.35 2.26 1.03 3.72 2.33 1.05 4.00 2.41 1.08 4.18 2.50 1.09 4.33 2.56 1.21 4.37 2.68 1.25
25.0 3.27 2.20 1.20 3.64 2.27 1.22 3.91 2.34 1.25 4.08 2.43 1.27 4.23 2.50 1.40 4.27 2.61 1.45
30.6 3.07 2.12 1.29 3.41 2.19 1.32 3.67 2.26 1.35 3.83 2.35 1.37 3.97 2.41 1.51 4.01 2.51 1.57
35.0 2.82 2.07 1.33 3.14 2.14 1.36 3.37 2.21 1.39 3.52 2.32 1.41 3.65 2.35 1.56 3.68 2.46 1.62
40.0 2.28 1.70 0.94 2.45 1.83 0.95 2.59 1.93 0.97 2.73 2.02 0.98 2.85 2.08 0.99 2.99 2.16 0.99
46.1 1.95 1.43 1.01 2.09 1.54 1.03 2.21 1.63 1.05 2.33 1.71 1.06 2.43 1.76 1.07 2.55 1.82 1.07
- 8 -
4-1. Cooling capacity
4. Capacity table
WALL MOUNTED ASUG09-12LMAS WALL MOUNTED ASUG09-12LMAS

Fujitsu ASUH12LMAS Specifications

General

Brand	Fujitsu
Model	ASUH12LMAS
Category	Air Conditioner
Language	English
