2. Dimensions
2-1. Models: AOUH09LEAS1 and AOUH12LEAS1
Unit: in (mm)
14-5/16 (363)
Top view
Side view
Front view
19-11/16 (500)
19-5/16 (490)
- 67 -
2-1. Models: AOUH09LEAS1 and AOUH12LEAS1
2. Dimensions
OUTDOOR UNIT
AOUH09-12LEAS1
OUTDOOR UNIT
AOUH09-12LEAS1
