Fujitsu ASUH12LMAS Design & Technical Manual

1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASUH09LMAS ASUH12LMAS
Power supply 208/230 V~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 2.64 3.52
Btu/h 9,000 12,000
Min.—Max.
kW 0.90—2.90 0.90—3.60
Btu/h 3,070—9,900 3,070—12,300
Heating
Rated
kW 3.19 3.52
Btu/h 10,900 12,000
Min.—Max.
kW 0.90—3.81 0.90—4.31
Btu/h 3,070—13,000 3,070—14,700
Heating
(17°F) *
1
Rated
kW 1.96 2.20
Btu/h 6,700 7,500
Max.
kW 2.89
Btu/h 9,850
Heating
(5°F) *
2
Rated
kW 2.37
Btu/h 8,100
Max.
kW 2.64
Btu/h 9,000
Input power
Cooling
Rated
kW
0.720 1.410
Min.—Max. 0.14—1.58
Heating
Rated 0.790 0.920
Min.—Max. 0.20—1.63
Heating
(17°F) *
1
Rated 0.74 0.76
Max. 1.41
Heating
(5°F) *
2
Rated 1.205
Max. 1.320
Current
Cooling
Rated A
3.4 6.4
Heating 3.7 4.3
EER2 Cooling
kW/kW 3.66 2.49
Btu/hW 12.5 8.5
COP2 Heating
kW/kW 4.04 3.82
Btu/hW 13.8 13.0
SEER2 Cooling Btu/hW 21.3 18.0
HSPF2 Heating Btu/hW 10.0 9.0
Power factor
Cooling
%
92.1 95.9
Heating 92.8 92.6
Moisture removal pints/h (L/h) 2.7 (1.3) 3.8 (1.8)
Maximum operating current*
3
Cooling
A
8.4
Heating 9.4
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
453 (770)
MED 353 (600)
LOW 265 (450)
QUIET 147 (250)
Heating
HIGH 453 (770)
MED 377 (640)
LOW 306 (520)
QUIET 182 (310)
Type × Qty Crossflow fan × 1
Motor output W 49
Sound pressure level*
4
Cooling
HIGH
dB (A)
43
MED 36
LOW 30
QUIET 19
Heating
HIGH 43
MED 38
LOW 33
QUIET 21
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 26-3/8 × 1-1/16 (210 × 670 × 26.6)
Main2: 4-7/16 × 26-3/8 × 13/16 (112 × 670 × 20)
Sub: 3-5/16 × 26-3/8 × 1/2 (84 × 670 × 13.3)
Fin pitch FPI
Man1: 21
Main2: 23
Sub: 18
Rows × Stages
Main1: 2 × 10
Main2: 2 × 7
Sub: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
10-5/8 × 32-13/16 × 8-3/4 (270 × 834 × 222)
Gross 10-7/8 × 36 × 13-1/16 (277 × 914 × 332)
Weight
Net
lb (kg)
22 (10)
Gross 29 (13)
Connection pipe
Size
Liquid
in (mm)
Ø 1/4 (Ø 6.35)
Gas Ø 3/8 (Ø 9.52)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm) Ø 17/32 (Ø 13.8) (I.D.), Ø 19/32 to 21/32 (Ø 15.0 to 16.8) (O.D.)
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Remote controller type
Wireless (Wired, Mobile app*
5
[FGLair
™
] [option])
- 2 -
1. Specifications
WALL MOUNTED ASUG09-12LMAS WALL MOUNTED ASUG09-12LMAS

Fujitsu ASUH12LMAS Specifications

General

Brand	Fujitsu
Model	ASUH12LMAS
Category	Air Conditioner
Language	English
