4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ASUH09LMAS
AFR CFM 453
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
5 3 9.55 1.28 9.38 1.30 9.01 1.32 8.94 1.34 8.67 1.36
14 12 10.30 1.35 10.07 1.37 9.69 1.39 9.59 1.41 9.35 1.43
23 19 10.75 1.39 10.17 1.41 9.90 1.43 9.83 1.45 9.55 1.47
32 28 11.29 1.46 10.78 1.48 10.44 1.50 10.27 1.52 9.93 1.54
41 37 12.80 1.53 12.25 1.55 11.87 1.57 11.64 1.59 11.26 1.61
47 43 13.99 1.57 13.38 1.59 13.00 1.61 12.73 1.63 12.32 1.65
50 47 14.74 1.59 14.09 1.61 13.65 1.63 13.38 1.65 12.93 1.67
59 50 15.52 1.36 14.64 1.36 13.99 1.35 13.82 1.35 13.44 1.35
68 59 15.29 1.13 14.40 1.12 13.78 1.12 13.68 1.12 13.24 1.12
75 64 15.66 1.11 14.77 1.10 14.13 1.10 14.02 1.10 13.58 1.10
AFR
m
3
/h
770
Indoor temperature
°CDB 15.6 18.3 21.1 22.2 23.9
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 2.80 1.28 2.75 1.30 2.64 1.32 2.62 1.34 2.54 1.36
-10.0 -11.1 3.02 1.35 2.95 1.37 2.84 1.39 2.81 1.41 2.74 1.43
-5.0 -7.2 3.15 1.39 2.98 1.41 2.90 1.43 2.88 1.45 2.80 1.47
0.0 -2.2 3.31 1.46 3.16 1.48 3.06 1.50 3.01 1.52 2.91 1.54
5.0 2.8 3.75 1.53 3.59 1.55 3.48 1.57 3.41 1.59 3.30 1.61
8.3 6.1 4.10 1.57 3.92 1.59 3.81 1.61 3.73 1.63 3.61 1.65
10.0 8.3 4.32 1.59 4.13 1.61 4.00 1.63 3.92 1.65 3.79 1.67
15.0 10.0 4.55 1.36 4.29 1.36 4.10 1.35 4.05 1.35 3.94 1.35
20.0 15.0 4.48 1.13 4.22 1.12 4.04 1.12 4.01 1.12 3.88 1.12
24.0 18.0 4.59 1.11 4.33 1.10 4.14 1.10 4.11 1.10 3.98 1.10
¢
Model: ASUH12LMAS
AFR CFM 453
Indoor temperature
°FDB 60 65 70 72 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
5 3 9.55 1.28 9.38 1.30 9.01 1.32 8.94 1.34 8.67 1.36
14 12 10.30 1.35 10.07 1.37 9.69 1.39 9.59 1.41 9.35 1.43
23 19 11.33 1.41 11.09 1.43 10.68 1.45 10.58 1.47 10.27 1.47
32 28 12.76 1.48 12.52 1.50 12.04 1.52 11.91 1.54 11.60 1.56
41 37 14.33 1.55 14.06 1.57 13.51 1.59 13.38 1.61 13.00 1.63
47 43 15.59 1.59 15.25 1.61 14.70 1.63 14.54 1.65 14.13 1.67
50 47 16.34 1.61 16.00 1.63 15.39 1.65 15.25 1.67 14.81 1.69
59 50 17.81 1.36 16.82 1.35 16.07 1.35 15.73 1.35 15.46 1.35
68 59 17.54 1.13 16.55 1.12 15.83 1.12 15.49 1.12 15.22 1.12
75 64 17.98 1.11 16.96 1.10 16.21 1.10 15.87 1.10 15.59 1.10
AFR
m
3
/h
770
Indoor temperature
°CDB 15.6 18.3 21.1 22.2 23.9
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 2.80 1.28 2.75 1.30 2.64 1.32 2.62 1.34 2.54 1.36
-10.0 -11.1 3.02 1.35 2.95 1.37 2.84 1.39 2.81 1.41 2.74 1.43
-5.0 -7.2 3.32 1.41 3.25 1.43 3.13 1.45 3.10 1.47 3.01 1.47
0.0 -2.2 3.74 1.48 3.67 1.50 3.53 1.52 3.49 1.54 3.40 1.56
5.0 2.8 4.20 1.55 4.12 1.57 3.96 1.59 3.92 1.61 3.81 1.63
8.3 6.1 4.57 1.59 4.47 1.61 4.31 1.63 4.26 1.65 4.14 1.67
10.0 8.3 4.79 1.61 4.69 1.63 4.51 1.65 4.47 1.67 4.34 1.69
15.0 10.0 5.22 1.36 4.93 1.35 4.71 1.35 4.61 1.35 4.53 1.35
20.0 15.0 5.14 1.13 4.85 1.12 4.64 1.12 4.54 1.12 4.46 1.12
24.0 18.0 5.27 1.11 4.97 1.10 4.75 1.10 4.65 1.10 4.57 1.10
