Fujitsu ASYG12LMCA Design & Technical Manual

¢ Floor type
MODEL: AGYG09LVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
-5.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
0.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
5.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
10.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
15.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
20.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
25.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
30.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
35.0 1.88 1.27 2.26 1.54 2.55 1.76 2.88 2.28 3.08 2.49 3.17 2.85
40.0 1.63 0.96 1.96 1.17 2.22 1.33 2.51 1.72 2.68 1.88 2.76 2.16
46.0 1.39 0.69 1.67 0.84 1.89 0.96 2.13 1.25 2.28 1.36 2.35 1.56
MODEL: AGYG12LVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
-5.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
0.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
5.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
10.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
15.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
20.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
25.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
30.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
35.0 2.50 1.58 3.01 1.93 3.40 2.20 3.84 2.84 4.10 3.11 4.23 3.56
40.0 2.18 1.20 2.62 1.46 2.96 1.66 3.34 2.15 3.57 2.35 3.68 2.69
46.0 1.85 0.86 2.23 1.05 2.52 1.20 2.84 1.55 3.04 1.70 3.13 1.95
MODEL: AGYG14LVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
-5.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
0.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
5.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
10.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
15.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
20.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
25.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
30.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
35.0 2.92 1.79 3.51 2.19 3.97 2.49 4.48 3.23 4.79 3.53 4.94 4.04
40.0 2.54 1.36 3.06 1.66 3.45 1.89 3.90 2.44 4.17 2.67 4.29 3.06
46.0 2.16 0.98 2.60 1.20 2.94 1.36 3.31 1.77 3.54 1.93 3.65 2.21
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
- 375 -
