76
How to operate the Sound Adjustment Mode
Selecting an equalizer mode from memory
Press a preset button to select the equalizer mode set in
memory for the button. The buttons that set equalizer modes in
memory are called preset buttons.
Turn the [SEL] button to select EQ.
Press the [SEL] button.
Select any button, from [1] to [5], and press it for less
than two seconds.
The preset pattern stored in memory will be retrieved.
Press the [RTN] button.
At this time, other adjustments can also be made in normal
mode.
Press the [SOUND] button for less than one second to
exit sound adjustment mode.
5
4
3
2
1
[SOUND] button
[SEL]
button
Buttons [1] to [5]
[RTN] button
ATTENTION
When the preset value is changed, the display shows as follows:
P
1~5 (Preset ch No.)
