FUJITSU Storage ETERNUS AF, ETERNUS DX Configuration Guide (Power Synchronized Unit)
Copyright 2019 FUJITSU LIMITED P3AM-8012-14ENZ0
43
4. Connection and Settings
This chapter describes the installation and setting procedures for a power synchronized unit and an AC sensor
unit.
If your sales representative or maintenance engineer does not perform the settings of the power synchronized
unit and the AC sensor unit, perform the settings yourself.
For the connection and setting details of a device that is connected to the power synchronized unit, refer to the
manual that is provided with the connected device.
■ Workflow
Perform the following procedure for connection and settings:
1 Set the ETERNUS DX/AF.
For details, refer to "Setting the ETERNUS DX/AF" (page 44).
2 Turn on the power synchronized unit.
For details, refer to "Turning on the Power Synchronized Unit" (page 48).
3 When five or more ETERNUS DX/AF storage systems are installed, connect the cascade cables.
For details, refer to "Connecting Cascade Cables" (page 51).
4 Connect the power synchronized unit to the server UPS unit.
For details, refer to "Connecting the Server UPS Unit to the Power Synchronized Unit" (page 54).
5 When three or more server UPS units are connected, connect the AC sensor unit.
For details, refer to "Connecting the AC Sensor Unit" (page 55).
6 Connect the power synchronized unit to the ETERNUS DX/AF.
For details, refer to "Connecting to the ETERNUS DX/AF" (page 57).
End of procedure
Attach labels to each cable that is to be connected and make a note of the connection source and destination.
This helps with cable management and prevents incorrect connections.
To Next Page
