Fujitsu FP-510 User Manual

69 / 125
(2) Serial interface connector
Pin No.
Signal name
I/O direction
Function
1
FG
---
Frame ground
2
TXD
Output
Send data
3
RXD
Input
Receive data
4
RTS
Output
Send request
5
CTS
Input
Send permission
6
DSR
Input
Data set ready
7
SG
---
Signal ground
8 to 12
N.C.
---
Unused
13
SG2
Input
+24 V ground
14
SG2
Input
+24 V ground
15 to 17
N.C.
---
Unused
18
+24V
Input
Power supply for mechanism drive
19
+24V
Input
Power supply for mechanism drive
20
DTR
Output
Data terminal ready
21 to 24
N.C.
---
Unused
25
INIT
Input
Forced reset
Caution: To supply power from the power connector, do not connect the pins
shaded( )in the above table.
Caution: Use inch- screws to secure the connection.

Fujitsu FP-510 Specifications

General

Brand	Fujitsu
Model	FP-510
Category	Printer
Language	English
