Getting started
Connecting the mouse
You can connect a USB mouse or a PS/2 mouse to y our device.
Mouse,Connecting,
Connecting a USB mouse
► Connect the USB mouse to on e of the USB ports on the device.
USBport,USBp ort
Connecting a PS/2 mouse
If you do not attach a m ouse to the PS/2 mouse port, you can disable the mouse
controller in the BIOS Setup in order to free the IRQ12 for a d ifferent application.
► Connect the PS/2 mouse to the PS/2 mouse port of the device.
PS/2mouse,Connecting,PS/2mouse,
Connecting the keyboard
Keyboard,Connecting,
Connecting a USB keyboard
Use the supplied keyboard cable only.
USBport,Connecting,
► Plug the rectangular connector of the keyboa
rd cable into the rectangular socket
on the underside or on the rear of the keyboard
.
► Insert the flat rectang ular USB plug of the keyboard cable into one of the device’s USB ports.
USBport
Connecting a PS/2 keyboard
Use the supplied keyboard cable only.
ConnectingaP
S/2keyboard
Connecting,
► Plug the rectangular connector of the keyboard cable into the rectangular socket
on the underside or on the rear of the keyboard.
► Plug the round plug of th e keyboard cable into the
keyboard port on the device.
Keyboard,
Connecting external devices to the parallel or serial port
ParallelportSerialportParallelportSerialportExternaldevicesDevices
External devices can be connected to the parallel or serial port (e.g. a printer or a modem).
► Connect the data cable to the external device.
► Depending on the device, connect the data cable to the parallel port or the serial port.

For an exact description of how to connect external devices to the corresponding
port, please see the external device documentation.
Port settings
ParallelportSerialport,
You can change the port settings (e.g. address, interrupt) in the BIOS Setup.
Fujitsu Technology Solutions 15
