System expansions
Opening the casing
Casing,Device,
► Switch the device off. The device must not be in power-saving m ode.
Please observe the sa fety information in "Important notes", Page 6.
Disconnect the mains plug from the mains outlet.
Only insert the power plug after you have closed the casing.
► Remove any connected wires which are in the way.
3
2
2
11
► Loosen the screws at the rear (1).
► Slide the casing cover in the direction of the arrow (2).
► Lift off the casing cover (3).
22 Fujitsu Technology Solutions
