System expansions
1
4
5
3
2
► Connect the plug of the DVI adapter cable to t he mainboard (1).
► Place the DVI-D monitor port in the slot (2). Ensure that you insert the lug (3)
on the port correctly into the intended opening (4).
► Ensure that the locking lug (5) engages.
► Refit the cross piece.
► Close the casing.
32 Fujitsu Technology Solutions
