5.1.6 Signal Routing
Some signal can be routed depending on the application of the evaluation board.
Jumper Setting Description
PULLDOWN – P10_7
Pull-down resistor is connected to P10_7
S21
P10_7
P10_7 – PULLUP
Pull-up resistor is connected to P10_7
P224 – CN2_B68
P242 – CN3_A6
P22_4 is connected to CN2_B68
P24_2 is connected to CN3_A6
S32/S33
P224/P242
P224 – CN3_A6
P242 – CN2_B68
P22_4 is connected to CN3_A6
P24_2 is connected to CN2_B68
P225 – CN2_B67
P243 – CN3_A5
P22_5 is connected to CN2_B67
P24_3 is connected to CN3_A5
S34/S35
P225/P243
P225 – CN3_A5
P243 – CN2_B67
P22_5 is connected to CN3_A5
P24_3 is connected to CN2_B67
Default: S21 = PULLDOWN – P10_7
S32 = P224 – CN2_B68 S33 = P242 – CN3_A6
S34 = P225 – CN2_B67 S35 = P243 – CN3_A5
