Fujitsu MB91460 - Hardware Requirements

Getting Started
Chapter 2 Hardware Requirements
© Fujitsu Microelectronics Europe GmbH - 7 - MCU-AN-391005-E-V17
2 Hardware Requirements
The chapter lists the required hardware for the MB91460 emulation system.
The MB91460 emulator system consists of
- the emulator MB2198-01 incl. 16 V DC power supply
- the DSU-FR cable MB2198-10
- the MB91V460 adapter board (MB2198-300) incl. 16 V DC power supply
- and an evaluation board, e.g.
- the evaluation board SK-91460-MAIN V1.2 incl. 9 V DC power supply
or
- the evaluation board SK-91F467-208PFV V1.1 incl. 9 V DC power supply and
- the probe cable PB-91467-208PFV or the probe cable PB-91467-LS-208PFV
