178
3. Select the "Correct skewed character strings automatically" checkbox.
4. Click the [OK] button to close the window.
⇒ The setting is enabled from next scanning.
ATTENTION
Up to +/-5 degrees of skews can be corrected.
This function determines a document skew based on the characters printed on
the document, so it may not work properly for the following document:
• Documents on which the pitches of lines or characters are extremely narrow,
or characters are overlapped
• Documents with many outline characters or using font styles like this
• Documents with many photographs or figures and only a few characters
• Documents with a background pattern behind characters
• Documents on which characters are printed in various direction (e.g. plans)
• Documents with long diagonal lines
• Documents with handwritten characters
*When you scan such documents, clear the checkbox.
