9.3 Replacing the Pick Roller
ScanSnap S510 Operator's Guide 241
Replacing Consumables and Carrier Sheet
9
9.3 Replacing the Pick Roller
Replace the Pick roller following the procedure below.
1. Remove the documents on the paper chute.
2. Open the ADF while pulling the cover open lever.
3. Adjust the Side guide to the "A5" size.
ADF
Cover open lever
Paper chute
A5
A5
To Next Page
