D
ScanSnap S510 Operator's Guide 259
Appendix D
Installation Specifications
The following table summarizes the installation specifications of this scanner.
Note) Dimensions
Item Specifications
Dimensions
(Note)
Width Depth Height
Minimum 284 mm
11.18 in.
157 mm
6.18 in.
158 mm
6.22 in.
Maximum 284 mm
11.18 in.
436.7 mm
17.19 in.
299.5 mm
11.79 in.
Weight 2.7 kg (approximately 5.95 lb)
Input power
supply
Voltage 100 - 240 V (varies regionally)
Number of
phases
Single-phase
Frequency 50/60 Hz
Power
consumption
During
operation
28 W or less
During standby 6 W or less
Temperature/
Humidity
Allowable
Ranges
Scanner state During operation During standby During storage/
transportation
Temperature 5 to 35 (°C)
41 to 95 (°F)
-20 to 60(°C)
-4 to140 (°F)
-20 to 60(°C)
-4 to 140 (°F)
Humidity (%) 20-80 8-95 8-95
