E-10
CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT (Continued)
• Connect the video signal cable to the HDMI input terminal, component video input terminal, S-video input terminal, or the video input
terminal.
• If the component to be connected is equipped with HDMI output terminal, component video output terminal, it is recommended to connect to the
component video terminal.
SATELLITE TUNER
Display bottom
To S-video output
To video output
To component video output
To audio outputs
To video input
To S-video input
To audio inputs To component video input
To HDMI output
To HD M I in p ut
Antenna (commercially available product)
MHD01661-02_E.book 10 ページ ２００４年１２月２２日 水曜日 午後５時１５分
To Next Page
