Pick Roller
5. Turn the bushing in the direction of the arrow.
Bushing
ATTENTION
Make sure that the pick roller is attached firmly. Otherwise, paper jams or other feeding
errors may occur.
6. Close the sheet guide.
Make sure that both sides of the sheet guide are locked firmly.
6. Close the ADF top section.
Replacing Consumables
