Fujitsu ScanSnap S1300i

Bushing
ATTENTION
Be careful not to touch the grease on the gear near the bushing.
4. Attach a new pick roller to the ScanSnap.
Insert the left end of the shaft into the left-side hole, and then slowly attach the right end of
the shaft into place.
Pick Roller
5. Rotate the bushing in the direction of the arrow.
Replacing Consumables for iX500
482
