No. Name Description
3 Top cover Open it to remove jammed documents or clean the inside of the
ScanSnap.
For details about how to clean the inside of the ScanSnap, refer to
"Cleaning the Inside of S1100i" (page 462).
4 [Scan/Stop] button Press this button to start or finish scanning.
Indicates the status of the ScanSnap as follows:
Blue (lit): Ready
Blue (flashing): Scanning
Orange (flashing): Error
5 Feeding section Insert the document here to load.
Side
No. Name Description
6 Tape seal Remove this tape seal after installing the software.
7 USB connector Used to connect a USB cable.
Parts and Functions
82
