7 Command-Line Interface
Event.0=StartFlash
Event: StartFlash
SubEvent.0=Count
Sub-event: Count
CompCount.0=1
Number of components
(may be 0)
NoError.0=0
Number of errors
Event.1=StartFlash
Event: StartFlash
SubEvent.1=Result
Sub-event: Result
ObjTypeName.1=MAH3091MC
Object type (component)
ObjName.1=Disk:PCI1.11.1.SCSI0.0.0
Relevant object
OldVersion FW.1=5207
Old FW/BIOS version of
the object
NewVersion FW.1=5208
New FW/BIOS version of
the object
LastCommand.1=
Last command of the CLI
Error.1=0
Error number in the event
of an error
ErrorText.1=ERROR[0]] faultless
execution
Description of the return
value
If an error occurs in the SVUMI.dll when a command is being executed, the
entries in the results file depend on the current phase of the StartFlash proc-
ess. The LastCommand.# field may contain the following entries:
l AddJob
l GetUpdatableComponentsS
l StartUpdate
l WaitForPreparedStatus
l DoFlashBoot
