Fujitsu SP-1125N User Manual

Scanner Overview
This section explains the main features of this product, the names of parts and their functions.
Main Features
The scanner is equipped with the following features:
● High speed scanning
Realizes a scanning speed of 20 ppm/40 ipm (SP-1120N) (*1), 25 ppm/50ipm (SP-1125N) (*1), or 30 ppm/60
ipm (SP-1130N) (*1). Furthermore, up to 50 sheets of documents (*2) can be loaded for continuous scanning
which enables you to quickly digitize a large volume of documents.
● Network connection
The scanner can be connected via a wired LAN.
Even with a network connection, the scanning speed is equivalent to that of a USB connection.
During a network communication, in order to prevent information leaks due to interception of communications,
you can encrypt scanned images. For details, refer to the Network Setup Tool for SP Series Help.
● Improved efficiency for pre-scan work
The scanner can perform "mixed batch scanning" which allows you to scan documents with different paper sizes
at once.
This simplifies the process of sorting the documents before scanning.
● Reduced work loss caused by multifeeds
The scanner has ultrasonic multifeed sensors that accurately detect "multifeed" errors where two or more sheets
are fed through the scanner at once.
This detection for overlapped documents is reliable even when scanning a mixed batch of documents with
different paper sizes, avoiding potential work loss.
● Centralized management of multiple scanners
With Scanner Central Admin Server, multiple scanners can be managed together.
For example, the application can be used to update the setting information and scanner drivers for all scanners
at once, and can be used to check the operating status of each scanner.
For details, refer to the Scanner Central Admin User's Guide.
*1:
When A4 size documents are scanned at 300 dpi using JPEG compression.
*2:When the paper weight is 80 g/m
2
(20 lb).
13

Fujitsu SP-1125N Specifications

General

Color scanning	Yes
Maximum scan size	210 x 297 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Scanner type	ADF scanner
Product color	Gray
Built-in display	No
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	PDF
Daily duty cycle (max)	- pages
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input voltage	100 - 240 V
Power supply type	AC
Power consumption (off)	0.3 W
Power consumption (sleep)	2 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	135 mm
Width	298 mm
Height	133 mm
Weight	2500 g
