Fujitsu SP-1125N User Manual

Setting Up the ADF Paper Chute (Feeder)
Documents loaded in the ADF paper chute (feeder) are fed into the ADF one by one when scanning starts.
Using the chute extensions 1 and 2 as described in the following procedure will feed documents smoothly.
1 Pull out the chute extension 1.
HINT
Make sure you hold the ADF paper chute (feeder) while pulling out the chute extension 1.
2 Pull out the chute extension 2.
HINT
Make sure you hold the ADF paper chute (feeder) while pulling out the chute extension 2.
Basic Operations
33

Fujitsu SP-1125N Specifications

General

Color scanning	Yes
Maximum scan size	210 x 297 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Scanner type	ADF scanner
Product color	Gray
Built-in display	No
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	PDF
Daily duty cycle (max)	- pages
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input voltage	100 - 240 V
Power supply type	AC
Power consumption (off)	0.3 W
Power consumption (sleep)	2 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	135 mm
Width	298 mm
Height	133 mm
Weight	2500 g
