Troubleshooting
This section explains about the countermeasures against paper jams and other troubles, items to check before
contacting your scanner service provider, and how to read the product label on the scanner.
ATTENTION
For details about other errors/troubles that are not covered in this section, refer to the scanner driver's Help.
When a Paper Jam Occurs
Remove the documents that are left in the ADF in the following procedure:
CAUTION
● Do not use force to pull out jammed documents, and make sure to open the ADF first.
● Be careful not to touch any sharp parts upon removing jammed documents.
● Be careful not to get things such as hair, a tie or necklaces caught inside the scanner
when removing jammed documents.
● The inside of the ADF may become extremely hot during operation. Be careful not to burn
yourself.
1 Remove all documents from the ADF paper chute (feeder).
2 Open the ADF.
For details, refer to How to Open the ADF (page 34).
CAUTION
When the ADF is open, it might close accidentally. Be careful not to get your fingers
caught.
87

Fujitsu SP-1125N Specifications

General

Color scanning	Yes
Maximum scan size	210 x 297 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Scanner type	ADF scanner
Product color	Gray
Built-in display	No
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	PDF
Daily duty cycle (max)	- pages
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input voltage	100 - 240 V
Power supply type	AC
Power consumption (off)	0.3 W
Power consumption (sleep)	2 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	135 mm
Width	298 mm
Height	133 mm
Weight	2500 g
